Huawei Isitepower-M 1PH Back-Up Kit 5KW Inverter 5KWh Battery Li-Ion

FEATURES

AC Output

— Rated Power Output: 6 kVA / 5 kW

— Output Voltage: 230 VAC/50Hz

— Max. Output Current: 25.8A

—Max. *** Input Power: 6kW

AC Input

— AC Input Voltage: 230VAC/50Hz

— Surge Protection: 3 kVA/5 kVA, 8/20 s

— Max. Input Current: 30

PV Input

— Start-up Voltage: 100VDC

— MPPT Voltage: 90-420VDC

— Max. Input Voltage (Voc): 435VDC

— Max. Input Current (Isc): 2 x 15 A

— Recommended PV Power: 5000 Wp

— No. PV Strings/MPPT Routes: 2/1

— Optimizer Compatibility: DC Mbus Compatible

— DC Surge Protection: 10 kA, 8/20 s, criterion C

— Max. Input Current per Strings: 15 A

General

— Communication: Wi-Fi

— Display: LED’s, NetEco

— Battery Module Capacity: 5 kWh per module

— Max. Output Power: 2.5kW per Module, 5kW per ESS

— Output/Input Voltage: 370-480VDC

— Cycle Life: 6000 cycles @ 25 C, 100% DOD

What’s in the box

— 1 x Huawei 5KW Isitepower-M ESS

Power Module / Inverter

— 1 x Huawei 5KWh Isitepower-M ESS Battery Module

Note

Must be installed by a qualified electrician with a wire man’s license, supplied by a certificate of compliance.

Designed for use with the Huawei IsitePower-M ESS Power Module. We recommend the purchase of the power module for maximum efficiency as designed for use of all features

This Product includes, Huawei Isitepower-M Mounting Base
